With over 50 years of experience in the flange product segment, we have built up one of the most comprehensive stock and delivery ranges in our industry.
We stock a wide range of flanges in accordance with EN1092-1, DIN, and ASME standards up to a nominal diameter of DN2000 in various materials. In addition, we are able to produce special flanges and custom machining at short notice.
EN1092-1 Type 11
DIN 2631 - DIN 2638
Nominal pressure range:
PN6 - PN400
Dimension range:
DN10 - DN2000
EN1092-1 Type 05
DIN 2527
Nominal pressure range:
PN6 - PN400
Dimension range:
DN10 - DN2000
EN1092-1 TYPE13
Nominal pressure range:
PN10 - PN40
Dimension range:
1/2" - 6"
DIN 2573
DIN 2576
EN1092-1 Type 01
Nominal pressure range:
PN6 - PN40
Dimension range:
DN10 - DN2000
DIN2642
EN1092-1 Type 02
EN1092-1 Type 32
Nominal pressure range:
PN6 - PN40
Dimension range:
DN10 - DN2000
DIN 2673
EN1092-1 Type 04
EN1092-1 Type 34
Nominal pressure range:
PN6 - PN40
Dimension range:
DN10 - DN2000
Unalloyed heat-resistant:
P250GH/C22.8, P265GH
Alloyed heat-resistant:
16Mo3, 13CrMo4-5; on request: 10CrMo9-10
Fine-grained structural steel:
P355N; on request: P355QH1
Stainless steel / V2A series:
1.4541; on request: 1.4301, 1.4307
Stainless steel / V4A series:
1.4571; on request: 1.4404
Stainless steel / V5A series:
upon request: 1.4539
Duplex:
upon request: 1.4462
Other dimensions and materials available on request
Numerous processing options
Flanges according to drawing on request
Flanges according to drawing on request
Standards:
ASME B16.5
ASME B16.47 Series A
ASME B16.47 Series B
BS3293
Class:
150 lbs – 2500 lbs
Dimension range:
1/2" - 24" (other dimensions available on request)
Standards:
ASME B16.5
ASME B16.47 Series A
ASME B16.47 Series B
BS3293
Class:
150 lbs – 2500 lbs
Dimension range:
1/2" - 24" (other dimensions available on request)
Standards:
ASME B16.5
Class:
150 lbs – 2500 lbs
Dimension range:
1/2" - 24" (other dimensions available on request)
Unalloyed heat-resistant:
A105, C21
Stainless steel
304/304L; on request: 316/316L
Cold-tough:
A350 LF2
Numerous processing options
Flanges according to drawing on request
Flanges according to drawing on request
